High Load Linear Actuators, Closed-Loop Piezo Piezo Linear Translators

  • High Force Linear Actuators
  • Displacement to 180µm
  • Pushing Forces to 4500N (990lbs)
  • Pulling Forces to 500N
  • Sub-msec Response
  • Sub-nm Resolution
  • Options: UHV, Low & High Temperature

The high load linear actuator family P-239 is based on a ceramic stack of piezoelectric materials for high performance, ultra-high resolution motion. They can be operated in static and highly dynamic mode, with 990lbs (450kg) load. These actuators provide sub-millisecond response and sub-nanometer resolution. The internal spring preload makes them ideal for high precision machining applications, such as diamond turning, out-of-round turning, etc.

Standard PZT actuator models can be operated in open loop operation and provide nanometer resolution. For highest precision, accuracy, and repeatability, the P-177.10 closed loop feedback sensor option is available, integrating ultra-high resolution strain gage position feedback sensors for operation with PI high performance servo control electronics (click here for details on Position Sensors and Closed Loop Operation).

P-239 high load precision actuator models are equipped with special Piezoelectric ceramic layers, providing displacement up to 180 µm at -1000 V operating voltage. For maximum lifetime, voltages in excess of -750 V are recommended only for short periods of time.

The PZT stack actuator is protected from large pulling forces by a stainless-steel case with internal spring preload. The standard translator tip and base have tapped holes. Select the P-239.95 ball tip option to help decouple off-axis or torque loads from the translator tip. For push/pull forces up to 5 N, the translator can be mounted by clamping around the case. For larger forces, the translator must be mounted by the base.

Application examples:
Static and dynamic positioning, optics, metrology, smart structures, precision machining, adaptive mechanics, vibration cancellation, switching, laser tuning, force generation for bending or compressing of material, etc.

Factory Installed Options:1)
P-177.10 Closed Loop Control Option, not for P-239.00

P-702.10 High Temperature Option

P-702.20 Low Temperature Option

P-703.20 High Vacuum Option

P-705.00 Positive Polarity

P-239.95 Ball Tip

1) When ordering the following options, change the last digit to 7, e.g. P-239.00 to P-239.07, and list options separately.

Accessories:
Extension cables & connectors.

P-239 High Load Linear Actuators, Piezo Stacks, Closed-Loop Control Option, (Linear Piezo Translators)

See "PZT Control Electronics" section for our comprehensive line of low noise, modular and OEM control electronics for computer and manual control.

TECHNICAL DATA: P-239

Models *

P-239.00

P-239.10

P-239.20

P-239.30

P-239.40

P-239.60

P-239.80

P-239.90

Units

Notes

Open loop travel
@ 0 to -1000 V

5

10

20

40

60

100

140

180

µm ± 20 %

A4

* Closed loop travel ³

5

10

20

40

60

100

140

180

µm

A5

* Integrated feedback sensor

-

-

SGS

SGS

SGS

SGS

SGS

SGS



B

* Closed / open loop **
resolution

0.1 / 0.05

0.2 / 0.1

0.4 / 0.2

0.8 / 0.4

1.2 / 0.6

2 / 1

2.8 / 1.4

3.6 / 1.8

nm

C4

Stiffness

1440

800

423

220

150

90

66

52

N/µm ± 20 %

D1

Force generation (blocked)

7000

8000

8400

8800

9000

9000

9200

9300

N ± 20 %

D2

Push/pull force capacity

4500 / 500

4500 / 500

4500 / 500

4500 / 500

4500 / 500

4500 / 500

4500 / 500

4500 / 500

N

D3

Torque limit (at tip)

1000

1000

1000

1000

1000

1000

1000

1000

mNm

D6

Max. operating voltage

-1000

-1000

-1000

-1000

-1000

-1000

-1000

-1000

V

A7

Electrical capacitance

70

120

245

460

660

1150

1550

2100

nF ± 20 %

F1

Dynamic operating current coefficient (DOCC)

17.5

17.5

17.5

17.5

17.5

17.5

17.5

17.5

µA/(Hz x µm)

F2

Unloaded resonant
frequency (f0)

12

10

8

6.5

5.6

4

3

2

kHz ± 20 %

G2

Standard operating temperature range

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

-40 to +80

° C

H2

Voltage connection

VH

VH

VH

VH

VH

VH

VH

VH



J1

* Sensor connection

-

-

L

L

L

L

L

L



J2

Weight without cables

85

94

112

148

184

256

328

400

g ± 5 %

K

Material case / end pieces

N-S

N-S

N-S

N-S

N-S

N-S

N-S

N-S



L

Length L

35.5

40

48.5

66.5

83

118.5

151

184

mm ± 0.5



Recommended Amplifier/Controller

B, J

B, J

B, J

B, J

B, J

B, J

B, J

B, J



M

* Closed loop models require the P-177.10 option and are supplied with calibration data sheets
** Noise equivalent motion with E-507 amplifier

P-239 Dimensions


For mounting guidelines click here
Custom design for volume buyers
