Piezo Plates and Piezo Shear Plates: Sizes and Options
Piezo plate transducers from PI are available in different sizes and polarizations for axial, lateral and shear mode operation. Standard piezo plates come in sizes from 1x1 mm to 60x80 mm and thickness from 0.1 mm to 30 mm. Thickness tolerances on the miniature plates are as tight as 20 microns. PZT shear plate transducers are available with sizes to 25x75 mm and thickness from 0.2 mm to 10 mm.
Hard and Soft Piezoceramic Materials
Piezoceramic plates and blocks are available in a variety of soft PZT and hard PZT materials and can be manufactured with a choice of electrode materials and configurations.
Why Consider Piezoelectric Plates from PI
PI Ceramic manufactures high quality piezoelectric plates, blocks, ultrasonic transducers, piezo actuators, piezo ceramic motors, and a variety of high precision piezo mechanisms. Our highly controlled manufacturing processes allow for production of piezoelectric elements that are very clean, with extremely tight tolerances and minimum batch-to-batch variations. With decades of piezo transducer design and manufacture experience, PI Ceramic piezo products excel in a wide range of industrial and medical applications
